What are the Technical Specifications of the 9km Compact LRF Module for Gimbal Cameras?
The 9km Compact LRF Module for Gimbal Cameras represents a significant advancement in laser rangefinding technology, offering exceptional performance in a compact form factor. This module integrates seamlessly with modern gimbal camera systems, providing precise distance measurement capabilities for surveillance, reconnaissance, mapping, and industrial inspection applications. With its impressive 9km detection range, this LRF module meets the demanding requirements of professional users who need reliable distance data in challenging environments.
How Does the 9km Compact LRF Module Enhance Gimbal Camera Performance?
Improved Target Acquisition and Tracking
The 9km Compact LRF Module For Gimbal Camera systems significantly enhances target acquisition and tracking capabilities by providing precise distance measurements up to 9 kilometers away. The module utilizes advanced laser pulse technology with a 1550nm wavelength, which is eye-safe and offers excellent atmospheric penetration for reliable ranging even in challenging visibility conditions. With a fast measurement rate of up to 10Hz, the module enables real-time distance updates critical for tracking moving targets. When paired with high-performance gimbal cameras, the system creates a comprehensive solution combining visual identification with precise spatial awareness, invaluable for border security, law enforcement, and military applications.
Advanced Stabilization and Measurement Accuracy
The 9km Compact LRF Module For Gimbal Camera incorporates sophisticated stabilization technologies including an integrated 3-axis gyro-stabilized system that compensates for vibrations and platform movements. With a distance measurement accuracy of ±1 meter at maximum range, operators can rely on precise data for critical applications. Advanced signal processing algorithms filter out noise and false returns, providing clean data even in complex environments. This exceptional accuracy extends across the entire operational range, from 5 meters to 9 kilometers, making it versatile for both close-range inspection tasks and long-distance surveillance. The compact dimensions (80mm × 65mm × 40mm) and lightweight design (approximately 350 grams) ensure the module doesn't compromise the gimbal's original stabilization performance.
Integration with Advanced Imaging Systems
The 9km Compact LRF Module For Gimbal Camera supports standard communication protocols including RS-422, RS-232, and CAN-BUS, enabling seamless data exchange with thermal cameras, daylight cameras, and multispectral imaging systems. This integration allows for features such as automatic focus adjustment based on measured distance and precise target location plotting when combined with GPS/INS systems. The module operates from a standard 12-28V DC power supply, drawing only 4W during active ranging, which minimizes power consumption. Its built-in automatic calibration and self-diagnostic functions ensure reliable operation in field conditions without frequent maintenance. When paired with image processing software, the system can automatically calculate target dimensions based on pixel count and measured distance.
What Are the Key Technical Parameters of the 9km Compact LRF Module?
Laser Specifications and Safety Features
The 9km Compact LRF Module For Gimbal Camera employs a Class 1M laser operating at 1550nm wavelength, providing an ideal balance between range capability and eye safety. The laser features a narrow beam divergence of just 0.5 mrad with an optimized pulse width of 8ns and a maximum pulse repetition frequency of 12kHz. This configuration provides excellent resolution for distinguishing between multiple targets in close proximity. The module incorporates sophisticated laser pulse analysis algorithms that can differentiate between first, last, and strongest returns, enabling accurate readings even with partial obstructions like foliage. Advanced temperature compensation mechanisms maintain consistent performance across the operational temperature range of -40°C to +70°C.
Environmental Durability and Mechanical Properties
The 9km Compact LRF Module For Gimbal Camera features an IP67 rating, making it fully protected against dust and temporary water immersion. The housing is constructed from aircraft-grade aluminum with a corrosion-resistant coating. Vibration resistance is certified to MIL-STD-810G standards, allowing deployment on helicopters, UAVs, and other platforms subject to significant vibration. The module can withstand shock impacts of up to 40G and operates in humidity ranges from 5% to 95% non-condensing. All external connectors are military-grade with gold-plated contacts and locking mechanisms to prevent disconnection during operation. The robust construction eliminates the need for frequent recalibration, maintaining a mean time between failures (MTBF) rating of over 30,000 hours.
Power Requirements and Data Interface Options
The 9km Compact LRF Module For Gimbal Camera operates on a wide input voltage range of 12V to 28V DC, with efficient power consumption of just 4W during active ranging and 0.5W in standby mode. Multiple communication interfaces include RS-422, RS-232, and CAN-BUS, all operating at configurable baud rates from 9600 to 921600bps. Data output includes distance measurements, signal strength indicators, and internal diagnostic information in industry-standard protocols. The module features a dedicated hardware trigger input allowing synchronization with camera exposure or other system events. Advanced power management includes built-in surge protection, reverse polarity safeguards, and automatic shutdown sequences. Configuration software enables detailed customization of operating parameters, and custom firmware development is available for specialized applications.
What Applications Benefit Most from the 9km LRF Module Integration?
Military and Defense Applications
The 9km Compact LRF Module For Gimbal Camera provides critical capabilities for military and defense operations. When integrated with surveillance gimbals, this module enables precise target ranging essential for threat assessment and response planning. Military reconnaissance aircraft and UAVs use this technology to maintain standoff distances while gathering intelligence. The module's accuracy helps forward observers direct artillery fire with increased precision, while border security operations benefit from early warning and response coordination. The system's compatibility with thermal imaging creates comprehensive day/night surveillance solutions for perimeter security. Naval vessels deploy these integrated systems for maritime domain awareness, allowing accurate identification of approaching vessels beyond visual range. The robust construction ensures reliable performance in extreme conditions, and the eye-safe laser classification permits training exercises in populated areas.
Surveying and Geospatial Mapping
The 9km Compact LRF Module For Gimbal Camera transforms modern surveying and geospatial mapping when mounted on aerial platforms. The module enables rapid and accurate distance measurements that complement photogrammetry techniques for enhanced 3D terrain modeling. Surveyors can capture measurements of inaccessible locations without physical contact, reducing project time and safety risks. In urban planning, the system provides precise building measurements that inform development decisions. The module's compatibility with GIS software allows direct integration of ranging data with geographical databases. When combined with GPS/INS systems, it contributes to creating accurate digital elevation models for infrastructure planning, flood risk assessment, and environmental monitoring. Mining operations utilize these systems for volumetric calculations, while the module's ability to function in various lighting conditions ensures consistent data collection throughout the day.
Industrial Inspection and Monitoring
The 9km Compact LRF Module For Gimbal Camera delivers exceptional value in industrial inspection scenarios. Power line inspection teams use these systems to assess transmission tower conditions without requiring technicians to approach high-voltage equipment. The module's precision enables detailed inspection of flare stacks, cooling towers, and other tall structures from safe positions. Oil and gas facilities benefit from inspections enhanced with precise ranging data to pinpoint potential issues in pipelines and equipment. When mounted on drones, the module provides critical distance data for maintaining safe separation from structures while gathering imagery. Wind farm operators employ these systems for blade inspection, calculating deflection to identify potential structural issues. The module's resistance to industrial contaminants ensures reliable performance in harsh environments, while its low-light capability enables round-the-clock monitoring of critical infrastructure.
Conclusion
The 9km Compact LRF Module for Gimbal Cameras represents cutting-edge technology in distance measurement, offering exceptional range, accuracy, and integration capabilities for professional applications. Its compact design, environmental durability, and advanced features make it an ideal solution for military, surveying, and industrial users requiring precise distance data. This module enhances gimbal camera systems with critical ranging information that transforms visual surveillance into comprehensive spatial awareness. As a leading manufacturer in the laser optoelectronics industry, Hainan Eyoung Technology Co., Ltd. excels in laser distance measurement solutions. Our strong R&D, production, and inspection capabilities, along with OEM/ODM/OBM services, ensure customer satisfaction and product excellence. Contact evelyn@eyoungtec.com for more information.
